TwoTrees TTC-H80 CNC Milling Machine
TwoTrees TTC-H80 CNC Milling Machine
Couldn't load pickup availability
PRODUCT SOLD IN KIT TO BE ASSEMBLED
NB IT IS A DIY PRODUCT, NO TRAINING SUPPORT ON THE USE OF THE PRODUCT WILL BE PROVIDED.
The TTC-H80 is a high-capacity CNC milling machine designed for those who need a larger workspace and more power. Thanks to its sturdy aluminum alloy frame and standard 500W spindle (expandable), it ensures stable and deep machining on a wide range of materials, including hardwood, MDF, plastic, acrylic, and soft metals. The touchscreen control panel, Wi-Fi support, and GRBL software compatibility make it a versatile solution for both semi-professional workshops and advanced users seeking large-scale precision.
Main features
- Reinforced aluminum alloy structure to reduce vibration and increase precision
- Large working area: 460 x 460 x 80 mm, suitable for even large panels and complex projects
- Standard spindle: 500W brushless, up to 3000W optional, speed regulation 8000~30000 RPM
- 3.5" resistive touchscreen control for offline operation and quick settings
- Connections: USB, 2.4GHz Wi-Fi, TF Card for maximum flexibility of use
- Software Compatibility: Open source GRBL, Vectric, Fusion360, Carveco Maker, EASEL and more
- Processing of wood, MDF, acrylic, carbon fiber, aluminum, copper and stainless steel
- ER11 collet system, supports tools from 0.5 to 7 mm
- Maximum engraving precision: ±0.05 mm
- Certifications: CE, FCC, RoHS
TTC-H80 Technical Specifications Table
| Voice | Detail |
|---|---|
| Work area | 460 x 460 x 80 mm |
| Machine dimensions | 772 x 727 x 425 mm |
| Net weight | 19.5 kg |
| Structure | Aluminum alloy |
| Spindle | 500W brushless (Opt: 800W/1.5kW/3kW) |
| Spindle speed | 8000~30000 RPM |
| Diet | 216W dual channel, 100-240V AC input |
| Check | 3.5" touchscreen (480x320px) |
| Supported file types | GRBL, CNC, and open-source lasers |
| Collar | ER11 (0.5 - 7 mm) |
| Workable materials | Wood, MDF, acrylic, aluminum, steel |
| Accurate engraving | ±0.05 mm |
| Compatible software | Vectric, Fusion360, EASEL, Carveco Maker |
| Connections | USB, Wi-Fi 2.4G, TF Card |
| Operating systems | Windows, MacOS, Linux |
| Certifications | CE, FCC, RoHS |
The TTC-H80 offers excellent expandability and adaptability: it can be upgraded with more powerful spindles and CNC and laser accessories, making it ideal for makers, small workshops and digital shops that want maximum application freedom in a small space.
