Precision you can count on
Using advanced structured infrared light technology, the Creality Otter Lite captures intricate details and textures with up to 0.02mm accuracy. Whether scanning small mechanical components or full-scale models, the results are crisp, clean, and ready for 3D modeling or printing.
Wide range of applications
Designed for flexibility, the Otter Lite can handle objects from just 10 x 10 x 10 mm³ up to 2000 x 2000 x 2000 mm³. It is suitable for everything from miniatures and engineering components to furniture, statues and human figures.
Lightweight and travel-friendly
Weighing just 390 grams, this scanner is perfect for mobile workflows. Its plug-and-play configuration makes it ideal for scanning in studios, labs or on-site environments, without the need for calibration or markers.
Safe and non-invasive technology
The scanner uses Class 1 infrared structured light, ensuring a safe experience for users, scanned objects, and even people and animals. It avoids flashes or intense laser emissions, making it gentle and convenient for frequent use.
Connect, scan, create
Creality's included CrealityScan software makes scanning easy for users of all skill levels. With features like auto-alignment, noise reduction, and mesh generation, you'll spend less time editing and more time creating.
| Scan Mode | NIR (binocular infrared structured light) | Precision | 0.05mm to 100mm [1] |
|---|---|---|---|
| 3D Resolution | 0.1-2mm | Scanning speed | Up to 30 fps |
| Minimum scan volume | 20mm x 20mm x 20mm | Single capture interval |
Short range mode 100mm*62mm to 120mm 160mm*130mm to 250mm Long range mode 352mm*254mm to 300mm 788mm*509mm to 600mm 1460mm*1017mm to 1200mm |
| Working distance | 120mm-1200mm | Color Mapping | YES |
| Alignment mode | Marker / geometry / texture | Output format | OBJ/STL/PLY |
| IMU | YES | Improved marker recognition | 8 NIR LEDs |
| Additional color light | 2 white LEDs | Laser Safety | Class I (eye safe) |
| Weight |
Main unit: 300g Lite Bridge: 306g |
Measure | 173mm*39mm*56mm |
| Calibration card | High precision glass calibration card | Wireless scanning | YES |
| Protocol | Wi-Fi 6, backwards compatibility | Wi-Fi Bands | 5GHz |
| Data transfer speed | Up to 30 fps | Data Interface | Type-C/USB3.0/USB2.0 |
| Input power |
USB3.0 5V 3A Wi-Fi 12V 2A |
System Support | Windows: Windows 10/11 (64-bit) Recommended: i7-Gen7+ CPU, Nvidia/AMD GPU, 16GB+ RAM Minimum: i5-Gen8+ CPU, 8GB+ RAM Mac OS: Recommended: Apple M1/M2/M3 16GB+ RAM Minimum: Intel i5-Gen8+ 8GB+ RAM Android Chip: Qualcomm Snapdragon 888++ OS: Android 10.0+ RAM: ≥6G iOS: Model: iPhone 13 (A15 Bionic) OS: iOS15+ RAM: ≥6G |
 OtterLite
|
 Otter
|
|
|
Scan Mode
|
NIR (binocular infrared structured light)
|
NIR (binocular infrared structured light)
|
|
Precision
|
0.05mm to 100mm [1]
|
Up to 0.02 mm at 60 mm [1]
|
|
3D Resolution
|
0.1-2mm
|
0.05-2mm
|
|
Scanning speed
|
Up to 30 fps
|
Up to 30 fps
|
|
Minimum scan volume
|
20mm x 20mm x 20mm
|
10mm x 10mm x 10mm
|
|
Single capture interval
|
Short range mode 100mm*62mm to 120mm
160mm*130mm to 250mm Long range mode 352mm*254mm to 300mm 788mm*509mm to 600mm 1460mm*1017mm to 1200mm |
Short range mode
100mm*62mm to 120mm 160mm*130mm to 250mm Long range mode 358mm*254mm to 300mm 784mm*509mm to 600mm 1350mm×840mm to 1000mm |
|
Working distance
|
120mm-1200mm
|
110mm-1000mm
|
|
Weight
|
300 g
|
390 g
|
|
Measure
|
173mm*39mm*56mm
|
165mm*37mm*59mm
|
|
Wireless scanning
|
YES
|
Supported in combination with wireless scanning accessories
|
|
[1] Accuracy is evaluated under laboratory conditions (the measurement object is a pair of 100mm balls), and actual results may be affected by operating environments such as temperature, vibration and other factors.
|
||
