TwoTrees 500W Spindle Kit for TTC450
TwoTrees 500W Spindle Kit for TTC450
Regular price
€159,99 EUR
Regular price
Sale price
€159,99 EUR
Taxes included.
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Characteristics and properties
- Voltage 230V
- Click-and-Install
- Speed of 12,000 rpm
- Ideal for metals and other materials
With this 500W spindle kit Click-and-Install by TwoTrees you can equip your CNC milling machine with a powerful 500 watt high-speed spindle.
The 500-watt spindle reaches a speed of 12,000 rpm and ensures quiet and fast heat dissipation for smooth engraving. It is ideal for engraving metals or other materials.
Thanks to the Smart Termination function, the spindle stops automatically as soon as the work is finished.
Note: the kit comes with a standard ER11 collet.
Suggestion: spindle runout is 0.01-0.033.
Technical data:
| Performance | 500W |
| Speed | 12,000 revolutions per minute |
| Maximum torque | 0.6 Nm |
| Dielectric strength | 400V |
| Insulation resistance | > 2 MΩ |
| Net weight of the spindle | 1.4kg |
| Total length of the engine | 199 mm (with motor and fan) |
