Forward AM Ultrafuse TPS 90A - 750g

Ultrafuse TPS 90A is an SEBS-based elastomer. Compared to other flexible 3D printing materials, it has a more rubber-like haptic feel and better anti-slip properties. Additionally, the material has low moisture absorption, which enables printing without pre-drying.

Highlights:

• Soft touch
• Anti-slip properties
• Reduced moisture absorption
• Excellent layer adhesion
• Excellent low-temperature flexibility

Ultrafuse TPS 90A

Ultrafuse TPS 90A was specifically developed for Fused Filament Fabrication (FFF) and offers an exceptionally soft-to-touch surface. Ultrafuse TPS 90A provides a non-slip and soft-to-touch surface, giving it unique haptics in fused filament fabrication. This material’s characteristics are accompanied by low moisture absorption and excellent layer adhesion, which creates a special smooth surface, making it the perfect choice for handles on household appliances, as well as gaskets and seals in small series.

Tips & Tricks

• Nozzle temperature: 260-280 °C
• Bed temperature: 70-90 °C
• Build chamber temperature: passive heating
• Nozzle diameter: ≥ 0.4 mm
• Bed modification: PEI, PI or glue
• Print speed: 10-30 mm/s

Material properties

• Shore A hardness: 89
• Abrasion resistance: 111 mm³
• Compression set at 23°C, 72h: 75 %
• Tensile strength at break: 7 MPa (XY), 2 MPa (ZX)
• Elongation at break: 280 % (XY), 9 % (ZX)
• Tear strength: 10 kN/m (XY), 5 kN/m (XZ), 4 kN/m (ZX)

BASF Quality Control

The best available raw materials are selected from renowned suppliers. Production on state-of-the-art, computer-controlled machinery ensures a consistent quality filament, even across different colors and batches. Performance will always be as expected.

All BASF products are 100% traceable to the origin.
