Forward AM Ultrafuse BVOH 350gr
Forward AM Ultrafuse BVOH 350gr
Couldn't load pickup availability
Ultrafuse BVOH water-soluble support filament has been designed to dissolve easily in water. Solubility increases with increasing water temperature. It offers excellent compatibility with a variety of materials: PLA, PLA PRO1, ABS, ABS Fusion+, PA, and PAHT CF15.
Features:
- Water-soluble
- Dissolves 2 times faster than other PVAs
- Multi-material compatible support
Ultrafuse BVOH
Printing complex designs may only be possible with temporary support structures. Ultrafuse BVOH water-soluble support filament has been designed to dissolve easily in water. Solubility increases with increasing water temperature. It offers excellent compatibility with a variety of materials: PLA, PRO1, ABS, ABS Fusion+, PA, and PAHT CF15. Store this monofilament in a sealed bag or container to prevent moisture absorption.
Tips and Tricks
- Nozzle temperature: 190 – 210 °C
- Bed temperature: 60 – 100 °C
- Bed material: Glass
- Nozzle diameter: ≥ 0.4 mm
Material Properties
- Tensile strength (MPa): 8.7 (ZX), 33.7 (XY)
- Flexural modulus (MPa): 1081 (ZX), 1807 (XZ), 2236 (XY)
- Elongation at break: 0.8% (ZX), 14.8% (XY)
- Melting temperature: 175 oC
| Basic Data | |
| Material | BVOH |
| Diameter | 2.85 mm |
| Weight | 0.35 kg |
| Length | 48 m |
| Color | Natural |
| Printing Parameters | |
| Minimum recommended printing temperature | 190 °C |
| Maximum recommended printing temperature | 210 °C |
| Minimum recommended bed temperature | 60 °C |
| Maximum recommended bed temperature | 100 °C |
| Minimum recommended printing speed | 30 mm/s |
| Maximum recommended printing speed | 60 mm/s |
| General | |
| Specific gravity | 1.138 g/cm³ ISO 1183-1 |
| Flexural | |
| Flexural strength | 50.3 MPa |
| Flexural modulus | 1807 MPa |
