Delta WASP 2040 Clay

Delta WASP 2040 Clay

Precise and fast using all ceramic materials. Open ceramic 3d printer accessible on three sides to interact during prints. Compact professional printer, makes prints up to 40 cm high.

Delta 3D printer Made in Italy, with a clean design and compact dimensions. The aluminum and steel structure guarantee stability and precision obtaining quality prints with dense fluid materials.

Technical specifications:

Maximum print volume: Ø200mm x h400 mm;
Minimum layer height: 0.5 mm;
Maximum printing speed: 150 mm/s;
Maximum movement speed: 150 mm/s;
Acceleration: 500 mm/s2;

Usable materials: ceramic mixes
Clay
Porcelain
Stoneware
Earthenware
Other

Configurable tools : LDM WASP extruder 3.0: with nozzle diameter 1.5, 2 and 3 mm (factory standard)
Luer lock adapter with conical nozzles diameter: 1.2 and 1.5 mm

Operating Systems: Windows, Mac, Linux;

Official Slicing: Simplify3D®

Compatible Slicers: Care, Slic3r

File type: .stl, .obj, .gcode;

Dimensions: 44 cm x 49 cm x h 87 cm;
Machine weight: 40 kg;

Dimensions for shipping with cardboard box on pallet: 50cm x 70cm x 101cm, weight 50kg.

Input: 220/240V 50/60Hz (110V available);
Power consumption: 180W

NB: compressor required (min. working pressure 8 bar)

MATERIAL INCLUDED:

1 LDM Wasp extruder 3.0 with metal nozzle diam. 1.5, 2 and 3 mm.
1 x 3L tank
1 marine plywood print plate
12.5 kg of red earthenware DISCOVER THE TECHNICAL DETAILS >>

Dimensions for shipping with cardboard box on pallet : 50cm x 70cm x 101cm, weight 50kg

NB. The 8 bar 50 L compressor and the tube connecting it to the 3D printer are not supplied by WASP.

A helpful tip: This is a nylon tube and is usually supplied by the compressor supplier. If you don't have it, you can buy it from any hardware store in the length you need, ask for 8mm or 5/16″ (outside dimension) nylon tube.
